Ever wondered how a touch-sensitive screen works? The answer is capacitive sensing, which can detect the presence of your finger through the protective glass sheet and doesn’t require any pressure. However, this perhaps under-appreciated technology is not limited to touch-sensitive displays: it is increasingly being utilized for many other established and emerging applications, ranging from automotive controls to leak sensing and even eye tracking.

How Does Capacitive Sensing Work?

Understanding the operating mechanism of capacitive sensors is key to understanding the applications to which they are well suited. Briefly, the sensors work via capacitive coupling to detect objects that have dielectric properties substantially different from air – fingers, being mainly water, work well. Since electric fields can travel through dielectric materials such as air or glass, there is no requirement for electrical contact. However, depending on sensitivity and readout methodology, the object being sensed often needs to be close to the patterned conductive layer, which is why it’s often difficult to use touchscreens or other capacitive controls while wearing gloves.

Opaque Touch Sensing

Although capacitive sensing is widely associated with touch-sensitive displays, it is also increasingly used on opaque surfaces. These include car steering wheel controls and touch panels – the conductive material used to make the capacitive sensor is sometimes a transparent metal mesh so that the controls can be backlit. Capacitive touch sensing is also an essential feature of in-mold electronics, in which conductive traces and LEDs are first printed/mounted on a flat substrate, then thermoformed, and finally, injection molded.

Moving from conventional mechanical switches to capacitive switches brings multiple benefits: fewer components, a reduction in materials used, an interface that can be wiped clean (since there are no grooves between buttons), and a sleek modern aesthetic. However, some drivers have expressed concerns that capacitive sensors are less tactile and hence more difficult to use while driving – integrating haptic feedback is a possible solution.

Leak Sensing

As anyone who has tried to operate their smartphone in the rain will attest, capacitive sensors are extremely sensitive to water due to its high dielectric constant. While this might be undesirable on a touch-sensitive display, it does enable capacitive sensors to be used for leak detection.

By utilizing low-cost materials such as carbon inks printed onto plastic using conventional methods, it is possible to produce rolls of printed/flexible sensors for just a few dollars. These can then be placed around plumbing, under kitchen appliances, and even along pipes – a small control unit housing a circuit board with a micro-controller and batteries measures the changing capacitance. If a leak occurs, a change in capacitance is detected, and a signal is sent to an app to provide a notification. This capability is proving compelling to insurance companies since limited capital investment would substantially limit the property damage caused by any leak.

Eye-Tracking

Perhaps the most surprising emerging application of capacitive sensors is an early-stage technology that provides eye-tracking for virtual/augmented reality glasses. Based on multiwalled carbon nanotubes (MWCNTs) embedded within paper to produce a conductive material with a very large surface area and hence high sensitivity to changes in the dielectric environment. Utilizing three sensors enables projected capacitance, in which the relative response of each sensor enables the location of the change in dielectric properties of the target object to be determined via triangulation. Compared to competing approaches such as machine vision, capacitive sensing promises a much shorter processing time and hence a more responsive system.


Technological and commercial readiness of capacitive sensing technologies and applications.

Emerging Printed & Flexible Sensor Technologies

IDTechEx’s report “Printed and Flexible Sensors 2022-2032: Technologies, Players, Markets” assesses the technologies and market landscape across 9 distinct printed sensor technologies: piezoresistive sensors, piezoelectric sensors, printed photodetectors, temperature sensors, strain sensors, capacitive touch sensors, gas sensors, biological sensors, wearable electrodes. The report draws on detailed profiles of over 50 companies, the majority based on interviews, to evaluate each of these printed sensor categories in considerable detail, evaluating the different technologies and the challenges to adoption. IDTechEx develop 10-year market forecasts for each technology and application sector, resulting in 33 individual forecast segments delineated by revenue and printed sensor area.
